Couldn’t you actually get it to fire on two cylinders reliably. if you used cylinders at position 1 and 5 and the distributor position 1 and 4.
wouldn’t tdc for the ignition stroke look kind of like this for the crankshaft angles?
8cyl 6cyl
0 0
90 120
180 240
270 360
360 480
450 600
540
630
I admit that this is 30 inches of snow in the last week, mental masturbation. It keeps worming it’s way into my brain because I would like a compressor that puts out more than 20 CFM. I had a gas driven one that put out 24 CFM but I burned in up in a fire a ways back and have never had the money to replace it. I have seen videos of VW beetle engines made to run on two cylinders and pump air with two which is kind of what got me to thinking. Not too worried about cylinder oiling just because this is a piece of equipment that would have very limited run time at any one time. Blocking a pair of intake runners and pulling outside air directly into a cylinder would be simple enough. Engines do run with misfiring cylinders.
firing order for the V-6 Is 1-6-5-4-3-2 and the earlier v-8 is 1-8-4-3-6-5-7-2. Obviously no way to get the two front or back cylinders in line with each other.
I appreciate you guys batting this around with me.
My first car in high school ws a 1953 chevy with a 235 cu. in. straight six engine and I had a tire inflator from the Sears Roebuck catalog that could replace a spark plug and had a hose long enough to air up all 4 tires. It had a check valve that allowed air in the cylinder on the downstroke and out the hose on the upstroke. Seems back then I always ran on poor tires and had to use it a lot.
13 Likes
I think you could do it on two running cylinders. What would happen if you replaced the spark plug with a reed valve? Both valves closed on the compression stroke aren’t they?
as a side note, most of the higher output compressors are two stage.
The OTHER way to possibly get around this, is if you just need a short burst of 30cuft is to get a bigger tank like an old well pressure tank. I think the metal ones are rated to like 200psi (but double check). But the ones with a bladder in them, the bladder goes bad, not the tank but the bladder is like 250 dollars and the new tank is only 100 bucks more and I don’t think any plumber or well person replaces the bladder.
2 Likes
I have replaced a couple of pressure tanks since we have lived here Sean. They are fairly thin metal compared to air compressor tanks I’ve built stuff with. I wonder just how much pressure they could hold. Two stage compressors are for building psi. A one stage will put out more CFM. I need volume and not pressure. A one stage pump is good for 125 psi. I have seldom used more than 100 at any give time, but yes. A suitable sized tank is an issue. I could put something together with the largest Harbor Freight air pump. It’s fairly cheap but takes a 5HP electric motor. There is at least another $350 to get one that will last more than a year like the $150 Chinese junk. Then I’m only getting 15 CFM which would be acceptable with something like an 80 gallon tank. I’m probably never going to do this project. I just want to hear opinions on the feasibility. Trapped in the house snow talk.
4 Likes
According to the AO Smith manual for the 86 gallon tank, max working pressure is 100psi and check valves need to be installed.
if you just need volume, an 212cc lawnmower engine is like 13.5cuft/min @3600 rpm, if you can get both upstrokes it doubles.
The largest HF air pump is 5hp? can’t you just run it with a 10hp garden tractor?
actually Ron Ohler might have an old 5hp electric motor he would be willing to part with that is most likely industrial… I don’t think I have one that big.
2 Likes
TomH.
If a fellow was to actually do this it would be much easier to go old inline six cylinder and convert every other cylinder. Just as some were three cylinder converted in the false hope for better milage.(you can search this up)
My last owned a 1984 Ford I-6 300 cid had large base tapered seat spark plugs.
Pull the pushrods on the three cylinders to deactivate the valves.
Grind flush the three cylinders pins on the inside of the distributor cap.
Do your through the spark plug holes plumbing.
Steve Unruh
7 Likes
That sound so cool. Did not know this. Thanks for the information.
2 Likes
This makes sense SteveU. Does uncomplicate the conversion perhaps quite a bit. Since variable cylinder management has been around for a while now I don’t see any issues with oiling on the unfired cylinders and since the rotating assembly is hopefully already balanced I can’t see how firing or not firing any given cylinder could cause any additional engine stress. Not an engineer. I could be overlooking something there. At any rate a compressor pumping air out of a water cooled cylinder would be a benefit for heat dissipation which is always an issue for air pumps. Oil in the air stream has to be eliminated regardless. Anyways it give me something to think about while we are waiting for another 6 inches of snow overnight.
2 Likes
Tom I am sorry to say that for fuel use economy the variable cylinder systems are all huge engine killing fails.
When GM Cadillac did this back when in the 1980’s the failure were attributed to lack of good high speed controls management.
Now that in the last 15 years GM, Dodge-Ram, and Honda all have turned their engines into oil sucking-burning failures.
Two there was failures in the switching valve train.
ALL have had develop the oil consumption problems later on the deactivated cylinders.
Those cylinders not kept combustion hot and uniform thermal stabilized. Increasing the mechanical wear in thier bores, pistons and rings.
Delete kit are extremely popular on the GM’s. Look it up.
For your air compressor idea no-matter as you just would not be using it that long hours after hours.
S.U.
6 Likes
GM switched from active fuel management to dynamic fuel management. Dynamic fuel management uses 17 cylinder patterns rather then the active fuel management that just shut off the same cylinders.
I am guessing they rotate what cylinders they deactivate on the fly now which evens out and prevents wear because they can fire 1-2-3, the first rotation then 4-5-6 the next time, which keeps everything lubed.
2 Likes
I’ve been looking at the Bourke engine as a potentially great engine for syngas. The problem is that they don’t make them anymore. In fact, they never made them on any kind of a commercial scale. There are a few open source projects with CAD files. Anyway, it’s interesting this engine likes to run lean and uses (allegedly) detonation vs. combustion.
Pretty cool…
Roger Richard has a great channel, and can speak to the Bourke engine probably better than anyone—he owns a few of the originals:
8 Likes
Yeah Troy,
Pretty cool. I wonder what emissions are like. Come to think of it I wonder what the exhaust smells like. Something more I can learn about engines. I’m going to study more on this.
Btw have you checked out Anthony Michell’s ‘barrel’ engine? Variable stroke and variable compression ratio on the fly! I thought it would be the ultimate multi-fuel engine.
Rindert
5 Likes
Hi All,
Now here is an IC engine design concept I’d never heard off. Five stroke done with a second heat energy harvesting cylinder.
All of the five and six strokes proposal IC engines I have read were doing this heat energy harvesting in the same cylinder.
Advanced piston steam external combustion engines DID do High pressure; then onto a larger diameter secondary cylinder energy harvesting. Compound steam. Even done out to three cylinder triple expansion piston steam engines. Marine. The Titanic.
Do watch out to 14:50 and past to the ending to hear the explanations of current real world challenges any new IC engine must meet anymore.
Stop believing in miracle savior solutions. Stop listening to maths guys who promote just based on a limited set of idealized operating conditions.
Go with Hard engineering. Having to ramp right up to current in-production standards of achievements. Compete. Or die on the vine.
Regards
Steve Unruh
9 Likes
This is an interesting design. It used two magnetic rotors and a plasma. And it is 30% more efficient then piston engine. Their prototype is like 400-500hp.
Apparently it does have combustion, but it is between the two rotors…
Is Astron's Omega 1 Engine Real? Here's Everything You Need To Know.
This is a straight forward article that doesn’t mention anything about magnetism either…
https://www.whichcar.com.au/features/how-the-astron-omega-1-engine-is-reviving-the-rotary-engine-concept
I’m posting a link to the company, the first article that i read had a bunch of click bait in it had a different description of it… It might do both…
3 Likes
It’s not clear to me exactly how this thing works, but a couple of statements make me skeptical:
“Perhaps the most attractive aspect of the Omega 1 is its emissions, or rather, lack thereof. The majority of the emissions produced by the Omega 1 is harmless water vapor, and while there may be some hazardous emissions like nitrogen oxide, the amount produced would be exponentially less than an average combustion engine. Astron has also noted, should it be made available, the Omega 1 could receive hydrogen fuels, which would eliminate those harmful emissions entirely.”
and
“How it works is a pair of gears are stacked on top of each other, with another set behind. Both gears are smooth save for a single respective tooth and notch, that rotate in a housing that Astron claims doesn’t require sealing due to the incredibly tight fit of less than 0.1mm.”
3 Likes
Watch the video. The clickbait version was way off. And even the wordy descriptions were a bit confusing.
Some one did post a “working video” of the concept. I don’t know if that was a fake or not. So i didn’t post the link for it.
3 Likes
You will definitely need to filter and dry the air before you use it. It would be nice to see one working.
3 Likes
But only Time-in-services, all year around, with a wide variety of users In-real-world-usages can ever prove an engines true worth:
I’ve sought out and owed four of these. True true video.
The vehicle they are wrapped up into makes a difference too. I am picky. I’ve been transporting 8 foot and even 10 foot long building materials inside of the 2003 Toyota Camry 4 door sedan.
Steve Unruh
9 Likes
These are the most reliable engines but what makes them better than any other? My engine experience is pretty much limited to small and big block chevy’s and I was never focused on longevity. The engines mentioned probably had superior lubrication. Something that kept both Ford and most Chrysler’s v-8’s off this list. In my opinion the thing that makes the 5.3 in my 2002 Silverado keep running at 300,000 miles, other than diligent maintenance, is robotics. Engines can be manufactured to much tighter specs than when they were mostly assembled by humans on engine assembly lines. Even back in the day, if someone had the skill and tools to blueprint any engine it was going to far outlast any factory assembled unit. Rumor was that all the 327’s in Checker Cabs that were getting hundred of thousands of city driving miles were taken to their factory and blueprinted.
