hello steve, the original GEET from paul pantone i tried some years ago…for a grass mower with 250ccm… half an hour runs, than not more, because the lighter part of gasoline in the bubbler goes up and reach the engine first, so also really nearby stinky exhaust…but the rest of the gasoline not works more! therefore pantone makes exhibition runs only for short time…i think he likes to find money by investors…people report of their builds, proud, but than they report nothing more, because it not works…
gillier seems to have taken up the idea, for me he looks serious, his idea is the same with the inner and outer pipe, but not mixing diesel with water, what pantone does, mixing water with fuel…
ciao giorgio
There are procedures for utilizing waste heat from internal combustion engines, one is the TEG process (thermoelectric element), the other is BMW Steamer. We have already discussed this method at Heat pump or generator using heat flow. However, when one examines all these procedures, one returns to the beginning and sees that the simplest and also the most effective method is to gasify wood and use gas directly in the engine.
Just started watching Uncle Tony. Smart.
I got some time these days before the holidays, which I dedicated to the gasifier for the tractor, …
I’m not clear on the top nozzles tone. Are they for some pre-heat prior to the ones in the reactor section? I have seen them on several builds but didn’t want to seem stupid by asking about them. I guess everyone else knows about them.
It looks really good, hmm, I wonder if I had to continue with mine now, you’ll be done soon, with your speed.
Jan, I’m a bit lazy in spring, but I don’t have the right speed, … Well, there’s some progress, I imitated Marcus a bit, or Wayne’s way - the ribs on the fire tube. The air-cooled grille or heat exchanger consists of 25 rectangular tubes, maybe I will weld additional metal strips to increase the area.
Looks amazing, Tone, great work!
Do you preheat the incoming air in the grate tubes? Is there openings in the bottom of the grate also?
Goran, below will be the supply of air to the air chamber, which will consist of another plate at a distance of 2 cm, then distribute the air along these rectangular tubes, below are holes 6.5 mm above and 8 mm above.
This actually does produce a result. But many people don’t understand the science…
The water droplets vaporize to steam when they are heated by the burning fuel. This increases power and efficiency. Some airplanes in world war II did this to increase power.
Rindert
A few more thoughts on the lower part of the hot zone, where I want to replace and save as much energy as possible, assuming that the upright grille will effectively transfer the heat of the gas to the fresh air and the gas cools down a lot. Then, so chilled, it would rise next to the hot zone and take away its heat, which is not good. Therefore, I have to surround the lower part of the hot zone with thin sheet metal, so a layer of hot gases for insulation will be created and the hot radiation will be reflected back inside, …
Pressure test of the air chamber seal at 1.5 bar, I must admit that I am not as good a welder as Marcus, it was leaking in 4 places, …
y’all keep blowing my head up but I enjoy seeing everyone doing this, fabrication is just a passion of mine and it looks pretty good when I take my time, but you have way more going on in your build so its impressive to only have a few small leaks in all that welding!
Tone, that looks like a space rocket after burner. You better start practicing your moon walk
Pics make it look big. What’s the firetube diameter?
I have to agree with Marcus, Tone. That is a lot of welds around the tops and bottoms of all those tubes. Only four leaks considering that at a certain point you had to weld around the backs of them mostly blind is impressive.
Exactly my thoughts too. There is some distance in welds. Only four leaks? Difficult, the pipes in the bottom.
The diameter of the inner smaller pipe is 20 cm , the diameter of the outer smaller pipe is 35 cm , the spacing between the nozzles in height is 10 cm and the distance from the lower nozzles to the restriction support plate is 20 cm , the restriction opening is likely to be a few cm higher , say 17-18 cm from the lower nozzles . The weight of this piece is approximately 20 kg.
JO , I think I’m “a little over the moon” .
Heat shield to retain heat in the hot zone and a ring that will fit in the bottom of the funnel, …
Someone else should put this together,. place the black barrel in the middle of the red barrel and cut the used expansion vessel and place it on the red barrel …
Tone, the tiny green barrel on top - what is it for?
As you know, gasification causes high heat and the process dries out too much, but you need to add liquid, what do you think, the barrel is probably a little too small and everything will overheat?
